Ryder 1000

Jaw Crusher

Specifications

Crusher Opening

1000mm x 600mm (37” x 24”)

Engine/Genset

T4F/STG V Cummins B6.7/180-210 kva Alternator

Hopper Volume

5m3 (7yd3) Standard

Weight

29,500kgs (65,000lbs)

Output Capacity (Max)

Up To 200tph (220 US Tons)

CSS (Min - Max)

40mm – 180mm (1.5″ – 7″)

Applications

Hard Rock, C&D, Rubble, Demolition

Powering Forward

with Hybrid Efficiency

CRUSHING CHAMBER

18% Mn long life wear parts for extended durability
90kW / 120Hp high-power crusher drive for efficient crushing
Reverse crushing
Full hydraulic adjustment
600mm (2ft) clearance under chamber to discharge recycled materials
Jaw jog function for safety unblocking

Power unit

Cummins B6.7 coupled with alternator (1500-1800RPM 50/60hz) fixed speed
Silent genset canopy – 88dB for reduced noise during operation
Powerlock quick release for onsite grid connection, providing 100% electric plug-in capability

DISCHARGE

Oversize 1m (40”) wide discharge conveyor fitted with 4-ply EP630 HD belt
Hydraulic folding and lowering for maintenance and transport as standard
Dust suppression covers and water sprinklers
Tunnel system to prevent rebar snagging, ensuring smooth discharging operation

FINES / DIRT BELT

180° radial discharge with option to operate in any position for flexibility
Regulate output size via 2nd deck feeder grizzly for tailored output requirements

FAQ

Does the Ryder 1000 take long to setup?

The Ryder 1000 has an unbeatable set up time and safety is at the core of the jaw crusher’s makeup.

How long does it take to convert the Sprinter 1500 from a 2 to 3 way split

Within 1 minute and zero manual labour you can convert the Sprinter 1500 from a 3 product to a 2 product machine.

What sort of Applications is the Ryder 1000 suitable for

The Ryder 1000 can be found crushing the heardest of granite rock and equally cater for difficult recycling and demolition materials due to its unique features. Hard Rock, C&D, Rubble, Demolition

What is the fuel consumption on the Ryder 1000

The fuel consumption for the Ryder 1000 is on average 10-11 litres per hour

Is the Ryder 1000 suitable for urban projects

The Ryder 1000 is perfect for urban projects thanks to its fully electric capability and exceptionally low noise output, making it an excellent choice for city environments.
